The brand-new Conti HSR 5 19.5" all-position tire provides ultimate flexibility in regional applications with a special focus on increased mileage, efficiency and handling. Designed with a new tread compound to provide higher durability and fuel efficiency for utility and delivery fleets, the Conti HSR 5 19.5" pattern performs well against curbing and scrubbing with high cut resistance over the lifetime of the tire. Furthermore, the full-width siping and open shoulder improves traction and handling, contributing to its 3PMSF and M+S rating. Designed with retreadability in mind, the Conti HSR 5 19.5" casing features full width belts that extend past the groove bottoms and pattern stiffness provides excellent lateral stability which reduces squirm and delivers even tire wear.
Technical details
- Sidewall
- Tread
- Pattern
- Selective polymers chosen for the new rolling resistance compound provide more flexibility between the polymer chains. This results in reduced friction leading to lower rolling resistance.
- Hybrid compound: The advanced application-optimized tread compound adds up to significant improvements in rolling resistance and mileage
- Plus Volume Pattern
- Reduced fuel consumption and increased mileage potential
- Narrowed groove widths result in increased pattern volume, improving wear resistance to guarantee high mileage performance
Product Range Conti HSR 5 - 19.5
(*) = Intelligent Tire Article
| Article No. | 05124460000 | ||
| Load Range | G | iTire | No |
| Tread Depth (32nds) | 16 | Max Speed (mph) | 87 |
| Static Loaded Radius (in) | 15.1 | Overall Inflated Diameter (in) | 32.0 |
| Overall Inflated Width (in) | 8.6 | Approved Rims | 6.00/6.75 |
| Loaded Section Width (in) | 9.3 | Tire Weight (lbs) | 60 |
| Min Dual Spacing (in) | 10.0 | Max Loaded Inflation - Single (lb, PSI) | 3970/110 |
| Revs per Mile | 647 | Max Loaded Inflation - Dual (lb, PSI) | 3750/110 |
| Article No. | 05124460000 | ||
| Load Range | G | iTire more info | Yes |
| Tread Depth (32nds) | 16 | Max Speed (mph) | 87 |
| Static Loaded Radius (in) | 15.1 | Overall Inflated Diameter (in) | 32.0 |
| Overall Inflated Width (in) | 8.6 | Approved Rims | 6.00/6.75 |
| Loaded Section Width (in) | 9.3 | Tire Weight (lbs) | 60 |
| Min Dual Spacing (in) | 10.0 | Max Loaded Inflation - Single (lb, PSI) | 3970/110 |
| Revs per Mile | 647 | Max Loaded Inflation - Dual (lb, PSI) | 3750/110 |
| Article No. | 05128420000 | ||
| Load Range | H | iTire | No |
| Tread Depth (32nds) | 16 | Max Speed (mph) | 87 |
| Static Loaded Radius (in) | 15.1 | Overall Inflated Diameter (in) | 32.0 |
| Overall Inflated Width (in) | 8.6 | Approved Rims | 6.75 |
| Loaded Section Width (in) | 9.3 | Tire Weight (lbs) | 62.5 |
| Min Dual Spacing (in) | 10.0 | Max Loaded Inflation - Single (lb, PSI) | 4190/120 |
| Revs per Mile | 647 | Max Loaded Inflation - Dual (lb, PSI) | 3970/120 |
| Article No. | 05655090000 | ||
| Load Range | H | iTire more info | Yes |
| Tread Depth (32nds) | 16 | Max Speed (mph) | 87 |
| Static Loaded Radius (in) | 15.1 | Overall Inflated Diameter (in) | 32.0 |
| Overall Inflated Width (in) | 8.6 | Approved Rims | 6.75 |
| Loaded Section Width (in) | 9.3 | Tire Weight (lbs) | 62.5 |
| Min Dual Spacing (in) | 10.0 | Max Loaded Inflation - Single (lb, PSI) | 4190/120 |
| Revs per Mile | 647 | Max Loaded Inflation - Dual (lb, PSI) | 3970/120 |
