Conti HSR 5

19.5" Regional All-Position for Over-the-Highway

The Conti HSR 5 19.5 all-position tire delivers ultimate flexibility in regional applications with increased focus on mileage, efficiency and handling. Designed with a new tread compound to provide higher durability and fuel efficiency for utility and delivery fleets, the Conti HSR 5 19.5 pattern performs well against curbing and scrubbing with high cut resistance over the lifetime of the tire. Full-width siping and open shoulder design improves traction and handling, contributing to its 3PMSF and M+S rating. Designed with retreadability in mind, the Conti HSR 5 19.5 casing features full width belts that extend past the groove bottoms and pattern stiffness provides excellent lateral stability which reduces squirm and delivers even tire wear.



Features & Benefits


Improved Tread Durability

  • New tread compound for improved rolling resistance and tread durability

High Stability

  • Developed to provide excellent lateral stability to minimize squirm and improve handling

Optimized Traction

  • Designed with full width siping for improved traction and handling during life of the tire

All-Weather Performance

  • Features Three Peak Mountain Snowflake (3PMSF) and Mud + Snow (M+S) designations




Vocations


Commercial Utility Trucks

  • Fleets, trucks and drivers responsible for hauling of materials or equipment in the on/off-road application
  • Utility trucks typically operate on short to intermediate runs on paved, gravel, and on/off-road surfaces
  • Tires exposed to low-to-high abrasion caused by aggressive surfaces and increased lateral scrub, twisting, turning, and curbing



Product Range Conti HSR 5

Article NumberTire SizeLoad/Speed IndexRim Diameter (in)Static Loaded Radius (in)Overall Inflated Diameter (in)Overall Inflated Width (in)Loaded Section Width (in)Minimum Dual Spacing (in)Revs Per MileTire Weight (lb)E2_3PMSF_labelApproved Rim(s)Load RangeMax Loaded Inflation-Dual (lb, psi)Max Loaded Inflation-Single (lb, psi)Max Speed (mph)Tread Depth (32nds)
05124460000225/70 R 19.5128/126N19.515.132.08.69.310.0647606.00, 6.75Load Range G3750/1103970/1108716
05128420000225/70 R 19.5130/128N19.515.132.08.69.310.064762.56.75Load Range H3970, 1204190, 1208716
225/70 R 19.5

Article Number

05124460000

Tire Size

225/70 R 19.5

Load/Speed Index

128/126N

Rim Diameter (in)

19.5

Static Loaded Radius (in)

15.1

Overall Inflated Diameter (in)

32.0

Overall Inflated Width (in)

8.6

Loaded Section Width (in)

9.3

Minimum Dual Spacing (in)

10.0

Revs Per Mile

647

Tire Weight (lb)

60

Approved Rim(s)

6.00, 6.75

Load Range

Load Range G

Max Loaded Inflation-Dual (lb, psi)

3750/110

maxLoadAtInflationDualPsi_label

Max Loaded Inflation-Single (lb, psi)

3970/110

maxLoadAtInflationSinglePsi_label

Max Speed (mph)

87

Tread Depth (32nds)

16

Intelligent Tire

Select

Article Number

05128420000

Tire Size

225/70 R 19.5

Load/Speed Index

130/128N

Rim Diameter (in)

19.5

Static Loaded Radius (in)

15.1

Overall Inflated Diameter (in)

32.0

Overall Inflated Width (in)

8.6

Loaded Section Width (in)

9.3

Minimum Dual Spacing (in)

10.0

Revs Per Mile

647

Tire Weight (lb)

62.5

Approved Rim(s)

6.75

Load Range

Load Range H

Max Loaded Inflation-Dual (lb, psi)

3970, 120

maxLoadAtInflationDualPsi_label

Max Loaded Inflation-Single (lb, psi)

4190, 120

maxLoadAtInflationSinglePsi_label

Max Speed (mph)

87

Tread Depth (32nds)

16

Intelligent Tire

Select
